Automatically complete the interconnection soldering process of the PV module busbar including the arrangement of the junction box end and the non-junction box,the cutting&bending of busbar and the soldering of ribbon and busbar.

When the number of adhesive tapes is pasted, the speed fast, replacing the manual labor greatly and improves the working efficiency, and the adhesive position is accurately.

Glass moving robot arm will move the glass to the transmission line and the paper picking robot arm remove the paper at the same time.

Cell strings laying up machine,working with Stringer.Cell strings are in parallel with the long side of the modules after conveyed in the Automatic Layup Machine,and adjusted mechanically and by CCD.

This unit is mainly applied to remove and clean the remains of excessive glue of the modules after laminated; it works self-acting cutting through program setting which can smoothly remove module’s redundant remains.

A fully automatic framing machine, integrating the functions of frame loading, gluing, frame catching, framing and conveying; it greatly improves the production efficiency by accomplishing the technological process of module’s gluing and framing.
